LIGHT SOURCE
Source: 4x8W RGBW LEDs
Lux: 881,7lx @3 m full
Source life expectancy: > 50.000 h
OPTICS
Beam angle: 15°
Field angle: 33°
Lens diameter: 42mm
Additional optics: 25° and 45° optional
COLOUR SYSTEM
Colour mixing: RGBW / FC
White presets: 3.200 K ~ 10.000K
DYNAMIC EFFECTS
Static colour mode: selection of static colour
Manual colour mode: manual adjustment of colour
Auto mode: built-in programs with execution speed adjustment
Sound mode: music activation through internal microphone and sensitivity control
BODY
Body: sturdy die-cast aluminium body conceived for long-time durability
Body colour: black
CONTROL
Protocols: DMX512
DMX channels: 4 / 6 / 8 / 14channel
Pixel control: 1 / 2 controllable sections
W-DMX: integrated, proprietary protocol compatible with WIFIBOX, WDBOX
Display: LED display user interface
IR: infrared sensor controlled by remote
Master/Slave: for synchronized operation of more units linked in a chain
|
|
ELECTRONICS
Dimmer: linear 0 ~ 100% electronic dimmer
Dimmer curves: 4 different dimming curves available
Operating temperature: 0° ~ +35°
Flicker: flicker free operation
ELECTRICAL
Power supply: 100-240 V – 50/60 Hz
BATTERY
Battery: 24V lithium
Estimated battery life in colour change mode up to: 12h
Estimated battery life in full-mode up to: 8h
Re-charge connection: power cable
Re-charge time: 5h/max
Battery status: LED battery status indicator
PHYSICAL
Cooling: passive cooling and fan-free
Signal connection: XLR 3p IN/OUT connectors
Power connection: IEC IN/OUT connectors
IP rating: 33
Dimensions (WxHxD): 500x82x172mm
Weight: 3,5kg
|
