LIGHT SOURCE
Source: 3x8W RGBWAP LEDs
CCT: W: 6.200K
CRI: 70
Luminous flux: 651,27lm
Lux: 337lx @3 m full
Source life expectancy: > 50.000 h
OPTICS
Beam angle: 25°
Field angle: 44°
Lens diameter: 38mm
Additional optics: 45° (optional)
COLOUR SYSTEM
Colour mixing: RGBWAP / FC
Colour wheel: virtual colour wheel with presets
DYNAMIC EFFECTS
Static colour mode: selection of static colour
Manual colour mode: manual adjustment of colour
Auto mode: built-in programs with execution speed adjustment
Sound mode: music activation through internal microphone and sensitivity control
BODY
Body: sturdy die-cast aluminium body conceived for long-time durability
Body colour: black
|
|
CONTROL
Protocols: DMX512
DMX channels: 6 / 8 / 10channel
Display: LED display user interface
Firmware upgrade: yes, via USB - DMX interface (UPBOX1) not included
IR: infrared sensor controlled by remote
Master/Slave: for synchronized operation of more units linked in a chain
ELECTRONICS
Dimmer: linear 0 ~ 100% electronic dimmer
Dimmer curves: 4 different dimming curves available
Strobe / shutter: 1 ~ 28 Hz, electronic
Operating temperature: -10° ~ +45°
Flicker: flicker free operation
ELECTRICAL
Power supply: 100-240 V – 50/60 Hz
Power consumption (at 230 V): 25,5W
Power consumption (at 120 V): 25,5W
Output (at 230 V): 47 units on a single power line
Output (at 120 V): 25 units on a single power line
PHYSICAL
Cooling: passive cooling and fan-free
Sospension and fixing: double hanging bracket suitable for safe hanging and for floor positioning
Signal connection: XLR 3p IN/OUT connectors
Power connection: IEC IN/OUT connectors
IP rating: 30
Dimensions (WxHxD): 187x152x187mm
Weight: 1,68kg
|
