LIGHT SOURCE Source: 3x8W RGBA LEDs Source life expectancy: > 50.000 h
OPTICS Beam angle: 25° Field angle: 44° Lens diameter: 38mm Additional optics: 45° (optional)
COLOUR SYSTEM Colour mixing: RGBA / FC White presets: 3.200 K ~ 10.000K Colour wheel: virtual colour wheel with presets Macros: built-in white presets
DYNAMIC EFFECTS Static colour mode: selection of static colour Manual colour mode: manual adjustment of colour Auto mode: built-in programs with execution speed adjustment Sound mode: music activation through internal microphone and sensitivity control
BODY Body: sturdy die-cast aluminium body conceived for long-time durability Body colour: black
|
|
CONTROL Protocols: DMX512 DMX channels: 4 / 9channel Display: LED display user interface Firmware upgrade: yes, via USB - DMX interface (UPBOX1) not included IR: infrared sensor controlled by remote Master/Slave: for synchronized operation of more units linked in a chain
ELECTRONICS Dimmer: linear 0 ~ 100% electronic dimmer Strobe / shutter: 1 - 28 Hz, electronic Flicker: flicker free operation
ELECTRICAL Power supply: 100-240 V – 50/60 Hz Power consumption (at 230 V): 25W Output (at 230 V): 30 units on a single power line
PHYSICAL Cooling: passive cooling and fan-free Sospension and fixing: double hanging bracket suitable for safe hanging and for floor positioning Signal connection: XLR 3p IN/OUT connectors Power connection: IEC IN/OUT connectors IP rating: 30 Dimensions (WxHxD): 187x152x187mm Weight: 1,6kg
|
