LIGHT SOURCE
Source:12x8W
RGBW LEDs
Luminous flux:2'241lm
Lux:1'813lx
@3 m full
Source life expectancy:>50.000h
OPTICS
Beam angle:19°
Field angle:36°
Lens diameter:38mm
Additional optics:45° (optional)
COLOUR SYSTEM
Colour mixing:RGBW / FC
CTC:CTC control through dedicated DMX channel
Colour wheel:virtual colour wheel with macros
Macros:several pre-build pixel macros with adjustable speed
DYNAMIC EFFECTS
Static colour mode:selection of static colour
Manual colour mode:manual adjustment of colour
Auto mode:built-in programs with execution speed adjustment
Sound mode:music activation through internal microphone and sensitivity control
BODY
Body:sturdy die-cast aluminium body
Body colour:black
|
|
CONTROL
Protocols:DMX512
DMX channels:
4 / 7 / 9 / 12 / 17channel
Pixel control:1 / 3
section control
W-DMX:optional, proprietary protocol compatible with WIFIBOX, WDBOX
Display:LED display user interface
Firmware upgrade:yes, via USB - DMX interface (UPBOX1) not included
IR:infrared sensor controlled by remote
Master/Slave:for synchronised operation of more units linked in a chain
ELECTRONICS
Dimmer:linear 0 ~ 100% electronic dimmer
Dimmer curves:4
selectable dimming modes available
Strobe / shutter:1 - 28
Hz, electronic
Operating temperature:0° ~ +45°
LED Control:flicker free operation
ELECTRICAL
Mains power supply:
100-240 V – 50/60 Hz
Max power consumption:73,6W
Max power consumption (at 120 V):71W
Output (at 230 V):18
units on a single power line
Output (at 120 V):7
PHYSICAL
Cooling:passive cooling and fan-free
Suspension and fixing:double hanging bracket suitable for safe hanging and for floor positioning
Data:USB port for USB WIFI transmitter (optional)
Signal connection:
XLR 3p + 5p IN/OUT connectors
Power connection:Seetronic powerCON IN/OUT connectors
IP rating:20
Dimensions (WxHxD):
1.000x56x168mm
Weight:3,3kg
|
