LIGHT SOURCE
Source: 12x8W RGBW LEDs
CCT: W: 6.600K
Luminous flux: 3'035,7lm
Lux: 3'113lx @3 m full
Source life expectancy: > 50.000 h
OPTICS
Beam angle: 16°
Field angle: 35°
Lens diameter: 38mm
Additional optics: 25° (inc) - 45° (op)
COLOUR SYSTEM
Colour mixing: RGBW / FC
Colour wheel: virtual colour wheel with presets
DYNAMIC EFFECTS
Static colour mode: selection of static colour
Manual colour mode: manual adjustment of dimmer and strobe
Auto mode: built-in programs with execution speed adjustment
BODY
Body: sturdy die-cast aluminium body conceived for long-time durability
Body colour: black
|
|
CONTROL
Protocols: DMX512
DMX channels: 4 / 9channel
W-DMX: optional, proprietary protocol compatible with WIFIBOX, WDBOX
Display: LED display user interface
Firmware upgrade: yes, via USB - DMX interface (UPBOX1) not included
IR: infrared sensor controlled by remote
Master/Slave: for synchronized operation of more units linked in a chain
ELECTRONICS
Dimmer: linear 0 ~ 100% electronic dimmer
Dimmer curves: 4 different dimming curves available
Strobe / shutter: 1 - 28 Hz, electronic
Operating temperature: -10° ~ +45°
Flicker: flicker free operation
ELECTRICAL
Power supply: 100-240 V – 50/60 Hz
Power consumption (at 230 V): 77W
Power consumption (at 120 V): 78W
Output (at 230 V): 17 units on a single power line
Output (at 120 V): 9 units on a single power line
PHYSICAL
Cooling: passive cooling and fan-free
Sospension and fixing: double hanging bracket suitable for safe hanging and for floor positioning
Data: USB port for USB WIFI transmitter (optional)
Signal connection: variants available
Power connection: variants available
IP rating: 44
Dimensions (WxHxD): 253x200x237mm
Weight: 3,3kg
|
