LIGHT SOURCE
Source: 60W RGBW Osram Ostar LED
Luminous flux: 1'230lm
Lux: (6°) 11'100 lx - (50°) 705lx @3 m full
Source life expectancy: > 50.000 h
OPTICS
Zoom: 6° - 50° motorised linear zoom
Lens diameter: 100mm
Lens type: high-quality glass lens optics
COLOUR SYSTEM
Colour mixing: RGBW / FC
CTC: CTC control through dedicated DMX channel
White presets: 2.800 K ~ 8.000K
Colour wheel: virtual colour wheel with presets
DYNAMIC EFFECTS
Auto mode: built-in programs with execution speed adjustment
Sound mode: music activation through internal microphone and sensitivity control
BODY
Pan angle: 540°
Tilt angle: 260°
Pan/Tilt resolution: bit 8 / 16 bit
Feedback: automatic repositioning after accidental movement
Body: aluminium structure with hi-resistance polycarbonate cover
Body colour: black, white finishing available
|
|
CONTROL
Protocols: DMX512
DMX channels: 13 / 16channel
Display: black OLED high resolution display
Firmware upgrade: yes, via USB - DMX interface (UPBOX1) not included
Master/Slave: for synchronized operation of more units linked in a chain
ELECTRONICS
Dimmer: linear 0 ~ 100% electronic dimmer
Dimmer curves: 4 different dimming curves available
Strobe / shutter: 1 - 30 Hz, electronic
Battery backup: battery backup for user operation without connecting to the main power
Operating temperature: -10° ~ +45°
Flicker: flicker free operation
ELECTRICAL
Power supply: 100-240 V – 50/60 Hz
Power consumption (at 230 V): 113W
Output (at 230 V): 22 units on a single power line
PHYSICAL
Cooling: forced air with low noise fan
Sospension and fixing: any position with quick-lock omega brackets
Signal connection: XLR 5p IN/OUT connectors
Power connection: Neutrik powerCON IN/OUT connectors
IP rating: 20
Dimensions (WxHxD): 253x329x205mm
Weight: 7kg
|
