LIGHT SOURCE
Source: 280W RGB + Warm White LED
CCT: 6.500K
CRI: > 92
R9: > 94
Luminous flux: (6°) 3'670 lm - (45°) 3'795lm
Lux: (6°) 29'900 lx - (45°) 1'590lx @3 m full
Lux: (6°) 10'764 lx - (45°) 572lx @5 m full
Source life expectancy: 70.000
Other: TM-30-15RF/RG: 90 / 99 - TLCI: > 85
OPTICS
Zoom: 6° - 45° motorised linear zoom
Field angle: 11° - 48°
Lens diameter: 125mm
Lens type: high-quality glass lens optics
COLOUR SYSTEM
Colour mixing: RGB + Warm White
CTC: CTC control through dedicated DMX channel, + / - green and magenta correction and amber shift activation by DMX
White presets: 2.800 K - 8.000K
Colour wheel: virtual colour wheel with presets
Macros: several pre-build macros with adjustable speed
DYNAMIC EFFECTS
Special features: linear crossfade from a white to any color and CTO applied on colours
BODY
Hardware on-board: OMEGA sockets for quick rigging (clamp included)
Pan angle: 540°
Tilt angle: 250°
Pan/Tilt resolution: 8/16bit
Feedback: automatic repositioning after accidental movement
Body: aluminium die-casting
Body colour: black
|
|
CONTROL
Protocols: DMX512, RDM, Art-Net, W-DMX
DMX channels: 13 / 15 / 16 / 18 / 22 / 23 / 27channel
W-DMX: included, wireless solution receiver
RDM: RDM ready for fixture remote monitor and settings
Display: LCD high resolution colour display with autoflip
Firmware upgrade: yes, via USB - DMX interface (UPBOX1) not included
ELECTRONICS
Dimmer: linear 0 ~ 100% electronic dimmer
Dimmer curves: different dimming curves available
Strobe / shutter: 1 - 30 Hz, electronic
Battery backup: battery backup for user operation without connecting to the main power
Operating temperature: -10° ~ +45°
Flicker: flicker free frequency with adjustable PWM
ELECTRICAL
Power consumption: 338 W
Power supply: 100-240 V – 50/60 Hz
Power consumption (at 230 V): 338W
Power consumption (at 120 V): 342W
Output (at 230 V): 8 units on a single power line
Output (at 120 V): 5 units on a single power line
Power factor: pF 0,99 @120 V - pF 0,95 @230 V
PHYSICAL
Cooling: combination of heat pipe cooling system and low noise fan
Sospension and fixing: any position with quick-lock omega brackets
Signal connection: Amphenol XLR 5p IN/OUT connectors
Data connection: Art-Net RJ45 IN/OUT
Power connection: Seetronic powerCON waterproof IN/OUT connectors
IP rating: 20
Dimensions (WxHxD): 308x448x230mm
Weight: 13,6kg
|
