LIGHT SOURCE
Source: 400W custom RGBW LED
CCT: Tunable 2.000 K ~ 10.000K
Luminous flux: 6'153lm
Lux: (10°) 22'361 lx - (45°) 2'166lx @3 m full
Lux: (10°) 8'050 lx - (45°) 780lx @5 m full
Source life expectancy: 50.000 h
OPTICS
Zoom: 10° - 45° motorised linear zoom
Lens type: HD anti-reflection lenses with achromatic coating
Focus: motorised with auto-focus
Other: high-quality flat-field projection
COLOUR SYSTEM
Colour mixing: RGBW / FC
CTC: CTC control through dedicated DMX channel
White presets: 2000 K ~ 8000K
Colour wheel: virtual colour wheel with presets
DYNAMIC EFFECTS
Shutter system: 4 shutter blades with position and ±30° angle adjustment, ±45° rotation of the complete framing system
Animation wheel: animation wheel with CW and CCW rotation
Rotating gobos: 7 rotating gobos + open, interchangeable, indexing
Gobo size: outer: 26,7 mm - image: 22 mm - thickness: 0,3 mm
FX generator: shutter macros with adjustable speed
Circular prism: 3f with bi-directional rotation, indexing
Frost: linear 0 - 100% frost filter
Iris: 5 - 100% motorised iris
BODY
Pan angle: 540°
Tilt angle: 270°
Pan/Tilt resolution: bit 16 bit
Feedback: automatic repositioning after accidental movement
Body: aluminium structure with hi-resistance polycarbonate cover
Body colour: black
|
|
CONTROL
Protocols: DMX512, RDM, Art-Net, W-DMX
DMX channels: 33 / 38 / 39channel
W-DMX: included, wireless solution receiver
RDM: RDM ready for fixture remote monitor and settings
Display: LCD high resolution colour display with autoflip
Firmware upgrade: yes, via USB - DMX interface (UPBOX1) not included
ELECTRONICS
Dimmer: linear 0 ~ 100% electronic dimmer
Dimmer curves: 4 different dimming curves available
Strobe / shutter: 1 - 28 Hz, electronic
Operating temperature: -10° ~ +45°
Flicker: flicker free operation
ELECTRICAL
Power supply: 100-240 V – 50/60 Hz
Power consumption (at 230 V): 463W
Power consumption (at 120 V): 467W
Output (at 230 V): 8 units on a single power line
Output (at 120 V): 4 units on a single power line
PHYSICAL
Cooling: combination of heat pipe cooling system and low noise fan
Sospension and fixing: any position with quick-lock omega brackets
Pan / tilt lock: pan / tilt locking for transportation and maintenance
Signal connection: Amphenol XLR 5p IN/OUT connectors
Data connection: Art-Net RJ45 IN/OUT
Power connection: Neutrik powerCON TRUE1 IN/OUT connectors
IP rating: 20
Dimensions (WxHxD): 408x676x257mm
Weight: 26kg
|
