LIGHT SOURCE
Source: 91x3W high-power white LED
CCT: from 2,700K to 5,600K
Luminous flux: (26° only TU) 3'696 lm; (26° only DY) 4'406 lm; (26°) 7'951lm @full
Lux: (26° only TU) 1'289 lx; (26° only DY) 1'524 lx; (26°) 2'759lx @5 m full
CRI: (only TU) 97; (only DY) 97,4; (@full) 95,4
R9: (only TU) 91; (only DY) 96,2; (@full) 86,4
TLCI: (only TU) 98; (only DY) 98; (@full) 98
TM30 Rf: (only TU) >95,5; (only DY) >91,7; (@full) >93,2
TM30 Rg: (only TU) <102,4; (only DY) <100,8; (@full) <103,2
Source life expectancy: > 50.000 hrs (L70B10 @Ta 25° C / 77° F)
OPTICS
Beam angle: optional 5° / 10° / 14° / 19° / 26° / 36° / 50° / 70° / zoom 15°-30° / zoom 25°-50°
Lens type: HD anti-reflection lenses with achromatic coating
Focus: manual
Other: see available accessories
COLOUR SYSTEM
Colour mixing: warm white + cold white
DYNAMIC EFFECTS
Shutter system: 3 layers blades system and fast rehabilitation of blade in case of out of frame blade
Gobo size: B, outer: 86 mm - image: 64,5 mm - thickness: 1,1 mm
Static mode: selection of static dimmer
Manual mode: manual adjustment of dimmer and strobe
Auto mode: built-in programs with execution speed adjustment
Special features: HIGH mode, AUTO mode and SILENT mode fan management
CONTROL
Protocols: DMX512, RDM
DMX channels: 1 / 2 / 3 / 5 / 11channel
RDM: RDM for remote monitoring and settings
Display: Graphic User Interface
Firmware upgrade: yes, via USB - DMX interface (UPBOX2) not included
Master/Slave: for synchronised operation of more units linked in a chain
|
|
ELECTRONICS
Dimmer: linear 0 ~ 100% electronic dimmer
Strobe / shutter: 1 - 25 Hz, electronic
Display battery: self-charging battery backup
Operating temperature: -10° ~ +45°
LED Control: flicker free operation
Selectable PWM: 600 ~ 25.000 Hz
ELECTRICAL
Mains power supply: 100-240V - 50/60Hz
Max power consumption: 265W
Output (at 230V): 11 units on a single power line
Power factor: 0,97
BODY
Body: sturdy die-cast aluminium body
Body colour: black
PHYSICAL
IP rating: 20
Cooling: low noise fan
Suspension and fixing: bracket for hanging and positioning
Signal connection: Amphenol XLR 5p IN/OUT connectors
Power connection: Neutrik powerCON TRUE1 IN/OUT connectors
Dimensions (WxHxD): 265x259x540mm
Weight: 7,3kg
CERTIFICATIONS / APPROVALS
: CE, cTUVus
BOX CONTENT
1 x ECLFWVW
1 x 1,5 meters power cable (SCHUKO plug - NEUTRIK POWERCON TRUE1 IP65)
User Manual
|
