Weight
9.1 kg
Optics
2-elements 5:1 zoom high-resolution optic system
Beam aperture: 8° to 40°
Fast motorised linear zoom
170 mm front lenses cluster
Light source
19 x 500 lumens RGBW High-Power LED source
Total luminaire output: up to 4,000 lumens
Rated life (L70): up to 40,000 hours
Flicker free sources management, suitable for TV applications and all video recorded events
Movement
Extremely accurate positioning
Moving-head operated via either 8- or 16-bit resolution
High-resolution stepper motors operated via microprocessors ensure extreme accuracy and smooth movements.
Pan and tilt automatic repositioning
Moving-head range : 540° (pan), 270° (tilt)
Colours
Sophisticated 4 colours RGBW mixed, reaching high Colour
Rendering Index
Uniform light beam with no colour shadows, and rich saturated and pastel colour-hues
4.29 billion colours (8 bit resolution)
Virtual colour wheel, including most usuals white colour temperature presets
Dynamic colour macro effect with variable speed
Effects
Graphical effects capabilities
Effects can be coupled with beam, wash or matrix applications
Built-in pattern effects with speed and fade controls for scenic applications
Dimmer / strobe
Electronic dimmer, allowing perfect light adjustment from 0 to 100% without colour variation
White or colour strobe effect, with speed adjustment from 1 to 25 flashes per second
Software features
Local DMX addressing of luminaire and optional parameters through its built-in LCD control panel
Remote DMX addressing of luminaire and optional parameters through a standard RDM DMX controller
Information menu including hour counter, temperature, software version
Hardware features
Graphic LCD display for addressing and special functions settings, with flip function
6 menu buttons to set the functions
Excess temperature protection
XLR 5 pin male and female connectors for DMX connection
powerCON TRUE1 male and female connectors for power connection
|
|
Control
DMX 512 protocol, through DMX cable or wireless system
DMX-RDM compatible
Stand-alone mode and Primary/Secondary modes
Local control panel, with LCD display
Choice of 3 DMX Modes (from 17 to 28 DMX channels)
Power supply
Electronic supply with active PFC
100 to 240 Volts – 50/60 Hz
Power 400 W maximum
Cooling system
Advanced cooling system
Self adjusting variable speed fans for quiet operation (Auto mode)
Selectable auto, stage & studio ventilation modes
Safety protection against temperatures excesses
Housing
Moving-head skeleton made of aluminium and steel metal plates
Heatsinks in aluminium
Moulded covers in self-extinguishing fire retardant ABS PC (V0 class)
Two sides handles for transportation
Four heavy-duty feet for better stability
IP20 protection rating
Exterior finish: black (Carbon)
Installation
Fastening brackets system: one Omega ¼ turn brackets designed for use with standard clamps
Mounting points: two ¼ turn locking fittings allowing installation of Omega brackets on luminaire
Safety cable attachment point
Operating parameters
Operating positions: all (device on floor or fixed to a support)
Maximum permitted ambient temperature (Ta max): 45 °C (113 °F)
Minimum permitted ambient temperature (Ta min): -10 °C (14 °F)
Minimum usage distance: 1.0 m (3.28 ft)
Compliance
EU (EMC):
EMC Directive 2014/30/EU
EU (LVD):
LVD Directive 2014/35/EU
Size
Product: 288 x 380 x 220 mm (l x h x d)
Flight-case Foam : 350 x 410 x 280 mm (l x h x d)
|
