LIGHT SOURCE
Source:9x8W
RGBWAP LEDs
Luminous flux:
(15°) 2'068lm
Lux:1'080lx@3 m
Source life expectancy:>50.000h
OPTICS
Beam angle:23°
Field angle:40°
Lens diameter:42mm
Additional optics:25° and 45° (optional)
COLOUR SYSTEM
Colour mixing:RGBWAP / FC
Colour wheel:virtual colour wheel with macros
Macros:several pre-build pixel macros with adjustable speed
DYNAMIC EFFECTS
Static colour mode:selection of static colour
Manual colour mode:manual adjustment of colour
Auto mode:built-in programs with execution speed adjustment
Sound mode:music activation through internal microphone and sensitivity control
BODY
Body:sturdy die-cast aluminium body
Body colour:black
|
|
CONTROL
Protocols:DMX512
DMX channels:
6 / 9 / 11 / 18 / 23
channel
Pixel control:1 / 3
section control
W-DMX:optional, proprietary protocol compatible with WIFIBOX, WDBOX
Display:LED display user interface
Firmware upgrade:yes, via USB - DMX interface (UPBOX1) not included
IR:infrared sensor controlled by remote
Master/Slave:for synchronised operation of more units linked in a chain
ELECTRONICS
Dimmer:linear 0 ~ 100% electronic dimmer
Dimmer curves:4
selectable dimming modes available
Strobe / shutter:1 - 25
Hz, electronic
Operating temperature:-20° ~ +45°
LED Control:flicker free operation
ELECTRICAL
Mains power supply:100-240 V – 50/60 Hz
Max power consumption:78,5W
Max power consumption (at 120 V):79W
Output (at 230 V):15
units on a single power line
Output (at 120 V):9
units on a single power line
PHYSICAL
Cooling:passive cooling and fan-free
Suspension and fixing:double hanging bracket suitable for safe hanging and for floor positioning
Data:USB port for USB WIFI transmitter (optional)
Signal connection:XLR 3p IN/OUT connectors
Power connection:IEC IN/OUT connectors
IP rating:30
Dimensions (WxHxD):
1.000x55x56mm
Weight:3,23kg
|
