LIGHT SOURCE
Source:
12x8W
RGBW LEDs
Luminous flux:2'224lm
Lux:1'813lx
@3 m full
Source life expectancy:>50.000h
OPTICS
Beam angle:19°
Field angle:36°
Lens diameter:38mm
Additional optics:
45° (optional)
COLOUR SYSTEM
Colour mixing:RGBW / FC
CTC:CTC control through dedicated DMX channel
Colour wheel:virtual colour wheel with macros
Macros:several pre-build pixel macros with adjustable speed,
DYNAMIC EFFECTS
Static colour mode:selection of static colour
Manual colour mode:manual adjustment of colour
Auto mode:built-in programs with execution speed adjustment
Sound mode:music activation through internal microphone and sensitivity control
BODY
Body:sturdy die-cast aluminium body
Body colour:black
|
|
CONTROL
Protocols:DMX512
DMX channels:4/7/9/12/17channel
Pixel control:1/3section control
W-DMX:optional, proprietary protocol compatible with WIFIBOX, WDBOX
Display:LED display user interface
Firmware upgrade:yes, via USB - DMX interface (UPBOX1) not included
IR:infrared sensor controlled by remote
Master/Slave:for synchronised operation of more units linked in a chain
ELECTRONICS
Dimmer:linear 0 ~ 100% electronic dimmer
Dimmer curves:4
selectable dimming modes available
Strobe / shutter:1 - 28
Hz, electronic
Operating temperature:0° ~ +45°
LED Control:flicker free operation
ELECTRICAL
Mains power supply:100-240 V – 50/60 Hz
Max power consumption:71W
Max power consumption (at 120 V):73,6W
Output (at 230 V):18
units on a single power line
Output (at 120 V):7
PHYSICAL
Cooling:passive cooling and fan-free
Suspension and fixing:double hanging bracket suitable for safe hanging and for floor positioning
Data:USB port for USB WIFI transmitter (optional)
Signal connection:XLR 3p IN/OUT connectors
Power connection:Seetronic powerCON IN/OUT connectors
IP rating:20
Dimensions (WxHxD):
1000x56x168mm
Weight:3,3kg
|
