LIGHT SOURCE
Source: 420W high-power white LED
CCT: 7.000K
Lux: (5°) 21'362lx @5 m
Lux: (50°) 1'173lx @5 m full
Source life expectancy: > 20.000 h
OPTICS
Zoom: 5° - 50° motorised linear zoom
Lens diameter: 120mm
Lens type: HD anti-reflection lenses with achromatic coating
Focus: motorised with auto-focus
COLOUR SYSTEM
Colour mixing: linear CMY
CTC: linear CTO correction 2.700 K ~ 6.000 K
Colour wheel: 8 colour filters
DYNAMIC EFFECTS
Rotating gobos: 7 rotating gobos + open, interchangeable, indexing
Gobo size: outer: 26 mm - image: 19 mm - max thickness: 2 mm
Fixed gobos: 6 fixed gobos + open, interchangeable
Gobo size: outer: 26 mm - image: 19 mm - max thickness: 0,5 mm
Circular prism: 3f with bi-directional rotation, indexing
Frost: linear 0 - 100% frost filter
Iris: 5 - 100% motorised iris
BODY
Pan angle: 540 - 630°
Tilt angle: 233°
Pan/Tilt resolution: bit 8 / 16 bit
Feedback: automatic repositioning after accidental movement
Body: aluminium structure with hi-resistance polycarbonate cover
Body colour: black
|
|
CONTROL
Protocols: DMX512, RDM, Art-Net, W-DMX
DMX channels: 19 / 21 / 28 / 29 / 36channel
W-DMX: included, wireless solution receiver
RDM: RDM ready for fixture remote monitor and settings
Display: LCD high resolution colour display
Firmware upgrade: yes, via USB - DMX interface (UPBOX2) not included
Hibernation: power safe mode when lost DMX
ELECTRONICS
Dimmer: linear 0 ~ 100% electronic dimmer
Strobe / shutter: 1 - 28 Hz, electronic
Battery backup: battery backup for user operation without connecting to the main power
Operating temperature: -20° ~ +40°
ELECTRICAL
Power supply: 100-240 V – 50/60 Hz
Power consumption (at 230 V): 492W
Power consumption (at 120 V): 501W
PHYSICAL
Cooling: combination of heat pipe cooling system and low noise fan
Sospension and fixing: any position with quick-lock omega brackets
Pan / tilt lock: pan / tilt locking for transportation and maintenance
Signal connection: Amphenol XLR 5p IN/OUT connectors
Data connection: Art-Net RJ45 IN/OUT
Power connection: Seetronic powerCON waterproof IN/OUT connectors
IP rating: 65 for temporary outdoor application, not for fixed installation
Dimensions (WxHxD): 441x740x316mm
Weight: 38kg
|
