LIGHT SOURCE
Source: 49 (7x7) x3W Warm White LED
CCT: 2.800K
Luminous flux: 5'462lm
Lux: 30'110lx @3 m
Source life expectancy: > 50.000 h
OPTICS
Beam angle: 6°
Field angle: 8°
DYNAMIC EFFECTS
Pixel patterns: pre-programmed dynamic and static patterns
FX generator: adjustable foreground/background colour, index, speed, direction
Manual colour mode: manual adjustment of dimmer and strobe
Auto mode: built-in programs with execution speed adjustment
BODY
Pan angle: 540°
Tilt angle: 270°
Body: aluminium structure with hi-resistance polycarbonate cover
Body colour: black
|
|
CONTROL
Protocols: DMX512, Art-Net, Kling-Net
DMX channels: 13 / 16 / 55 / 62 / 65channel
Master/Slave: for synchronized operation of more units linked in a chain
ELECTRONICS
Dimmer: linear 0 ~ 100% electronic dimmer
Dimmer curves: 4 different dimming curves available
Strobe / shutter: 1 - 20 flash(s), mechanical
Operating temperature: -10° ~ +45°
Flicker: flicker free operation
ELECTRICAL
Power supply: 100-240 V – 50/60 Hz
Power consumption (at 230 V): 202W
Power consumption (at 120 V): 208W
Output (at 230 V): 8 units on a single power line
PHYSICAL
Cooling: forced air with low noise fan
Sospension and fixing: any position with quick-lock omega brackets
Pan / tilt lock: pan / tilt locking for transportation and maintenance
Signal connection: Neutrik XLR 3p + 5p IN/OUT connectors
Power connection: Neutrik powerCON IN/OUT connectors
IP rating: 20
Dimensions (WxHxD): 379x471x288mm
Weight: 14kg
|
