LIGHT SOURCE
Source:260W
6 colour custom LEDs source (red, orange, green, royal blue, blue, lime)
CCT:2.800 K - 10.000K
Luminous flux:(17°) 4'653 lm - (57°) 7'896lm
@full
Lux:(17°) 1'678 lx - (57°) 344lx
@5 m full
CRI:90 @3.200 K; 89 @5.600K
R9:80 @3.200 K; 87 @5.600 K
TLCI:77 @5.600 K
TM30 Rf:87 @3.200 K; 81 @5.600 K
TM30 Rg:106 @3.200 K; 106 @5.600 K
Source life expectancy:>50.000h
OPTICS
Zoom:17° - 57°
half peak angle
Lens diameter:8'' - 200mm
Lens type:Fresnel zoom lens
Focus:manual
COLOUR SYSTEM
Colour mixing:
CTC:CTC control, + / - green correction, Tungsten emulation
White presets:2.800 K -10.000K
Colour wheel:virtual colour wheel with macros
Macros:several pre-build macros with adjustable speed
DYNAMIC EFFECTS
Static colour mode:selection of static colour
Manual colour mode:manual adjustment of intensity, CT, colour correction from knob
Auto mode:built-in programs with execution speed adjustment
Special features:linear crossfade channel from any white to any colour; virtual CTO on colours
BODY
Hardware on-board:filter frame, 8 doors barndoor, spigot
Pan angle:360°
with manual regulation
Tilt angle:340°
with manual regulation
Body:sturdy die-cast aluminium body
Body colour:black, white finishing available
Other:spigot 28 mm
|
|
CONTROL
Protocols:DMX512, RDM, rotatory knob
DMX channels:
1 / 2 / 5 - 1 / 5 - 2 / 7 / 9 / 12 / 13 / 16 / 19 / 21
channel
RDM:RDM ready for remote monitoring and settings
Display:Graphic User Interface
Firmware upgrade:yes, via USB - DMX interface (UPBOX1) not included
Other:16bit control of dimmer and colour
ELECTRONICS
Dimmer:linear 0 ~ 100% electronic dimmer
Dimmer curves:4
selectable dimming modes available
Strobe / shutter:1 - 30
Hz, electronic
Operating temperature:-10° ~ +45°
LED Control:flicker free frequency with adjustable PWM
Selectable PWM:600 ~ 25.000 Hz
ELECTRICAL
Mains power supply:100-240 V – 50/60 Hz
Max power consumption:260W
Output (at 230 V):11
units on a single power line
Power factor:>0,93
PHYSICAL
Cooling:combination of heat pipe cooling system and low noise fan
Suspension and fixing:bracket for hanging and positioning
Signal connection:Amphenol XLR 5p IN/OUT connectors
Power connection:Neutrik powerCON TRUE1 IN/OUT connectors
IP rating:20
Dimensions (WxHxD):
341x545x343mm
Weight:9,7kg
|
